Ibis Ripley AF V2
Ripley is good AF at pretty much everything.
Perfect for both seasoned shredders and stoked newcomers, the newest AF version packs the same fast, playful feel the Ripley is known for — into a tough aluminum package that’s ready for anything.
REAR TRAVEL
130mm
FRONT TRAVEL
140mm
WHEEL SIZE
29"
FRAME MATERIAL
Aluminum
Deore Build Specs
| Component | Specification |
|---|---|
| Fork | RockShox Pike, 15QRx110, 140mm |
| Shock | RockShox Deluxe Select 210mm x 52.5mm |
| Wheels | Ibis 933 Aluminum Rims, Ibis Hubs |
| Front Tire | Maxxis DHR II, 29" x 2.4", EXO, TR |
| Rear Tire | Maxxis Rekon, 29" x 2.4", EXO, TR |
| Brakes | SRAM G2 4-Piston |
| Rotors (F/R) | SRAM Centerline 6-Bolt 180F / 180R |
| Crankset | Shimano Deore M6120, 24mm spindle |
| Bottom Bracket | Shimano MT501 |
| Rear Derailleur | Shimano Deore M6100 SGS |
| Shifter | Shimano Deore M6100, Blend Clamp |
| Cassette | Shimano Deore M6100, 10–51T |
| Chain | KMC X12 |
| Headset | Cane Creek 50: ZS44 / ZS56 |
| Grips | Lizard Skins Single Clamp |
| Handlebar | Ibis Aluminum, 780mm |
| Stem | Ibis 31.8mm S–M: 40mm, L–XL: 50mm |
| Seatpost | KS Vantage Dropper S: 110–140mm, M–XM: 140–170mm, L–XL: 180–210mm |
| Saddle | WTB Silverado Fusion CrMo 142 |
GEOMETRY
